iDeal FR-77-18 18' Tilt Deck/Steel Plate Platform Frame Rack

$16,999.00
$15,382.00
(You save $1,617.00 )
(No reviews yet) Write a Review
SKU:
#FR-77-18
Availability:
Usually ships in 3-5 Business Days

The iDEAL FR-77 Series Tilt Deck Steel Plate Frame Rack is available in both 18’ and 20’ configurations. The FR-77 series is manufactured from high quality plate steel providing 7,700lbs. capacity and the ability to accommodate full frame and uni-body vehicles. Two 10 Ton towers enable 360 degree clear floor pulling using multiple precision cut tie down hole locations and universal anchoring system with adjustable height clamping assemblies. The FR-77 Series comes with Pull Chains and Hooks, Overhead Boom / Pull Tower Extension, Universal Wheel Stands and Vehicle Dollies.

Features

  • Tilt Deck Operation with 7,700lbs. Capacity with Drive On Ramps
  • Durable, Heavy Duty Plate Steel Construction
  • Universal Anchoring System with Adjustable Height Pinch Weld Assemblies
  • Two – 10 Ton Pulling Towers with Telescoping Heads
  • Adjustable Tower Collars
  • Overhead Boom Pull Tower Extension
  • Quick Disconnect Hydraulic Fittings
  • Two – 10′ Pulling Chains with Hooks
  • Two – High Quality Air/Hydraulic Pumps with Pressure Gauges
  • Universal Wheel Stand And Dead Vehicle Dolly
  • Powder Coat Finish

Specifications

Deck Length 18′
Deck Width 82.6″
Deck Height 19.7″
Pull Force Per Tower 10 Ton
Hydraulic Pressure 10,000 PSI
Required Air Pressure 100 – 120 PSI
Lifting Capacity 7,700 lbs.
Shipping Weight 5,071lbs.



Click here for Brochure

Click here for Manual
