CEMB EZ15 3D Wheel Balancer with 17" Touchscreen

The CEMB EZ15 3D Wheel Balancer with 17" Touchscreen is a professional, space-saving wheel balancing machine designed for tire shops, automotive repair facilities, dealerships, and service centers that need advanced balancing capabilities in a compact footprint. Featuring AutoAdaptive™ technology, Virtual Sonar, automatic wheel positioning, laser-guided weight placement, and an electromagnetic brake, the EZ15 delivers accurate balancing performance while simplifying everyday wheel service operations.

Designed to combine professional performance with intuitive operation, the CEMB EZ15 features a large 17" touchscreen display, automatic wheel data measurement, and a rapid 5-second balancing cycle. Its compact design makes it an excellent choice for automotive service facilities with limited floor space without sacrificing important balancing capabilities.

With capacity for wheel assemblies weighing up to 165 lbs., rim diameters up to 30", and overall tire diameters up to 36", the EZ15 provides a versatile solution for balancing passenger vehicle, SUV, and compatible light truck wheels.

Features and Benefits:

• Space-Saving Design: Compact construction provides professional wheel balancing capabilities while minimizing required floor space.
• 17" Touchscreen Display: Large touchscreen provides intuitive navigation, clear balancing measurements, and convenient access to operating functions.
• AutoAdaptive™ Technology: Advanced balancing software calculates acceptable residual imbalance tolerances based on wheel weight and dimensions to help minimize vibration.
• Automatic 3D Wheel Data Entry: Combines automatic distance and diameter measurement with Virtual Sonar width calculation to simplify wheel setup.
• Virtual Sonar Technology: Calculates wheel width without requiring an external sonar sensor for compatible steel rims.
• Automatic Measuring Gauge: Measures wheel distance and diameter for rims up to 28" and automatically selects the appropriate balancing program.
• Fast 5-Second Balancing Cycle: Provides rapid balancing measurements to help improve shop productivity.
• Automatic Approach System: Automatically positions the wheel near the corrective weight location, reducing unnecessary manual wheel rotation.
• Electromagnetic Wheel Brake: Holds the wheel securely in position during corrective weight placement.
• Laser-Guided Weight Placement: Integrated laser line helps technicians accurately position adhesive wheel weights inside the rim.
• Integrated LED Wheel Lighting: Illuminates the wheel interior to improve visibility during corrective weight installation.
• ALU-S 3D Balancing Mode: Supports adhesive weight placement on internal rim planes with specific corrective weight positioning guidance.
• Professional Balancing Programs: Includes SPLIT, OPT, ALU, and ALU-S 3D programs for a variety of wheel balancing applications.
• Manual Wheel Locking: Uses a quick-clamping manual locking system for secure wheel mounting.
• 30" Maximum Rim Diameter: Accommodates a broad range of passenger vehicle, SUV, and compatible light truck wheels.
• 36" Maximum Tire Diameter: Supports larger wheel and tire assemblies within the machine's operating limits.
• 165 lb. Maximum Wheel Capacity: Provides professional wheel balancing capability for a variety of automotive applications.
• 110V Single-Phase Operation: Designed for convenient operation using suitable standard single-phase electrical service.
• Professional CEMB Technology: Combines advanced wheel balancing software with intuitive operation and durable construction.

Specifications:

Standard Included Equipment and Accessories:

• CEMB EZ15 3D Wheel Balancer
• 17" Touchscreen Display
• Manual Quick-Locking System
• Quick Locknut Kit – Part #41FF83146
• Three-Cone Centering Kit – Part #41FF034416
• Rim Width Gauge – Part #46FC77653
• Wheel Weight Pliers/Hammer
• Integrated Laser Weight Placement System
• Integrated LED Wheel Lighting

Available Optional Accessories:

• Pro Kit (PROKIT): Optional wheel balancing accessory package for additional mounting applications.
• Pro Plus Kit (PROPLUS): Expanded accessory package for professional wheel service applications.
• CEMB Wheel Lift: Optional lifting equipment designed to assist technicians with positioning heavy wheel assemblies on the balancing shaft.
• Specialty Wheel Mounting Adapters: Additional CEMB mounting accessories are available for compatible specialty wheel configurations.

Space-Saving Professional Wheel Balancer:

The CEMB EZ15 is designed for automotive service facilities that need professional wheel balancing capabilities without dedicating excessive floor space to a large balancing machine.

Its compact construction makes it particularly well suited for smaller tire shops, independent automotive repair facilities, and service centers where available workspace is limited.

Despite its space-saving design, the EZ15 incorporates advanced technologies commonly associated with larger professional wheel balancers, including automatic measurement, AutoAdaptive™ balancing software, laser-guided weight placement, and a large touchscreen interface.

17" Touchscreen Display:

The CEMB EZ15 features a large 17" touchscreen designed to provide clear balancing measurements, intuitive navigation, and convenient access to operating functions.

The touchscreen interface simplifies machine operation by allowing technicians to select balancing programs, review corrective weight requirements, and access available functions directly from the display.

This user-friendly interface helps reduce operator training time and improves efficiency during routine wheel balancing procedures.

AutoAdaptive™ Balancing Technology:

One of the most important features of the CEMB EZ15 is its advanced AutoAdaptive™ balancing technology.

Rather than applying the same residual imbalance tolerance to every wheel, AutoAdaptive evaluates the wheel's weight and dimensions to calculate an appropriate acceptable residual imbalance value.

This approach helps technicians achieve smooth balancing results while avoiding unnecessary corrective weight application.

By optimizing balancing tolerances for individual wheel assemblies, AutoAdaptive can help improve ride comfort and reduce vibration-related customer complaints.

Automatic 3D Wheel Data Entry:

The CEMB EZ15 combines an automatic measuring gauge with Virtual Sonar software to simplify wheel data entry.

The automatic gauge measures wheel distance and diameter for rims from 12" to 28" and automatically activates the appropriate balancing program based on the selected weight placement configuration.

Virtual Sonar calculates wheel width for compatible steel rims, reducing the need for manual measurements or a separate external sonar sensor.

Together, these technologies help minimize setup time and reduce errors associated with manually entering wheel dimensions.

Virtual Sonar Wheel Width Measurement:

CEMB's Virtual Sonar technology uses advanced software to calculate rim width without requiring a conventional external sonar measuring device.

After the initial wheel measurements are entered, the software evaluates possible external correction planes and determines whether the balancing correction can remain within acceptable tolerance limits.

For compatible wheels, this process allows the machine to calculate the necessary correction without requiring manual rim width entry.

If the software determines that the calculated correction may exceed acceptable tolerances, the operator is prompted to enter the rim width manually.

Fast 5-Second Balancing Cycle:

The CEMB EZ15 provides a rapid balancing cycle of approximately five seconds, helping technicians complete routine wheel balancing measurements efficiently.

Combined with automatic data entry, touchscreen operation, and automatic wheel positioning, the fast balancing cycle helps reduce the time required to service multiple wheel assemblies.

This makes the EZ15 particularly useful for professional tire shops and automotive service facilities where productivity and consistent balancing results are important.

Automatic Approach System:

The EZ15 features CEMB's Automatic Approach system, which automatically positions the wheel near the required corrective weight location after completing a balancing cycle.

The system stops the wheel near the weight application position, reducing unnecessary manual wheel rotation and helping technicians quickly locate the proper corrective weight position.

Electromagnetic Wheel Brake:

The CEMB EZ15 includes an electromagnetic brake that holds the wheel in position during corrective weight placement.

The brake works with the Automatic Approach system to simplify corrective weight installation and reduce unwanted wheel movement.

This feature is particularly useful when balancing larger wheel assemblies that can be more difficult to position manually.

Laser-Guided Weight Placement:

The EZ15 features an integrated laser line that helps technicians identify the correct location for adhesive wheel weight installation.

The laser provides a visual guide inside the rim, reducing guesswork and helping improve the consistency of corrective weight placement.

Integrated LED lighting further improves visibility inside the wheel during balancing operations.

Professional Balancing Programs:

The CEMB EZ15 includes multiple balancing programs designed for different wheel configurations and corrective weight placement requirements.

• SPLIT: Allows corrective weight placement to be divided for applicable wheel configurations.
• OPT: Provides optimization functions to help reduce imbalance through appropriate tire and wheel positioning.
• ALU: Supports balancing procedures for alloy wheels and applicable adhesive weight configurations.
• ALU-S 3D: Supports adhesive weight placement on internal rim planes with specific corrective weight positioning guidance.

These programs provide technicians with additional flexibility when balancing a variety of passenger vehicle, SUV, and compatible light truck wheels.

Manual Wheel Locking System:

The CEMB EZ15 uses a manual wheel locking system with a quick-clamping locknut for secure wheel mounting.

The included centering accessories accommodate a variety of compatible wheel center bores, while optional specialty adapters are available for additional wheel configurations.

Because the EZ15 uses manual wheel locking, it does not require a compressed-air supply for normal operation.

Professional Wheel Capacity:

The CEMB EZ15 accommodates wheel assemblies weighing up to 165 lbs., rim diameters up to 30", rim widths up to 20", and overall tire diameters up to 36".

These capacities make the machine suitable for balancing a broad range of passenger vehicle, SUV, and compatible light truck wheels.

Actual wheel compatibility depends on the wheel's dimensions, weight, center bore, and required mounting accessories.

Recommended Applications:

• Professional Tire Shops
• Independent Automotive Repair Facilities
• Automotive Dealership Service Departments
• Compact Automotive Service Bays
• Passenger Vehicle Tire Service
• SUV and Light Truck Wheel Balancing
• Fleet Maintenance Facilities
• Automotive Service Centers with Limited Floor Space

Installation Requirements:

The CEMB EZ15 Wheel Balancer requires a suitable installation area with a stable, level floor and adequate clearance for wheel mounting, balancing operations, and technician access.

The machine operates on 110V single-phase electrical power. Customers should verify the required electrical connection, circuit protection, and available power supply before installation.

The EZ15 uses manual wheel locking and does not require an external compressed-air supply for normal operation.

The machine weighs approximately 243 lbs. (110 kg). Customers should verify delivery access, unloading requirements, and available installation space before purchasing.

Installation and calibration should be performed according to the manufacturer's instructions.

Manufacturer Warranty:

The CEMB EZ15 Wheel Balancer includes a limited manufacturer warranty covering parts for 3 years and labor for 1 year, with extended 5-year motor warranty coverage for qualifying equipment purchased in the United States after January 1, 2026.

Warranty coverage begins on the invoice date and is subject to CEMB USA's applicable warranty terms, conditions, exclusions, and proper equipment installation and use.

Why Choose the CEMB EZ15 3D Wheel Balancer?

The CEMB EZ15 combines advanced wheel balancing technology with a compact, space-saving design that makes it an excellent choice for professional automotive service facilities.

Its large 17" touchscreen, AutoAdaptive™ balancing software, automatic 3D wheel measurement, Virtual Sonar, laser-guided weight placement, electromagnetic brake, and rapid 5-second balancing cycle help technicians achieve consistent balancing results while improving productivity.

With capacity for wheel assemblies weighing up to 165 lbs. and rim diameters up to 30", the CEMB EZ15 3D Wheel Balancer with 17" Touchscreen delivers an excellent combination of professional performance, advanced technology, and space-saving convenience.
